SEESTAR BEAM-420 420W Beam Moving Head Light

Technical Specifications

I. Electrical Parameters

  • Voltage: AC100V~240V, 50/60Hz
  • Power: 600W
  • Lamp: 420W Lamp

II. Display and Control

  • Display: Dot matrix display with four tactile switches, 180° reversible display
  • Control Method: 16-channel international standard DMX512 control
  • X-axis: 540°, 16Bit (precision scanning)
  • Y-axis: 270°, 16Bit (precision scanning)
  • Other Functions: Remote lamp on/off control, auto-run mode, master-slave mode, sound-activated mode

III. Functional Systems

  • Color Wheel: 1 color wheel with 14 color filters + white light
  • Gobo Wheels:
  • 1 static gobo wheel with 13 gobos + white light (including 3 glass gobos)
  • 1 six-color prism (colorful effect)
  • Prisms: 1 effect lens (8+16+24 prisms) + 1 eight-facet prism
  • Strobe: Single-blade strobe with max. 13 flashes per second, selectable random strobe and pulse strobe
  • Dimming: 0%-100% linear dimming
  • Frost: Frost function supported

IV. Physical Attributes

  • IP Protection Class: IP20, with high-efficiency reliable switching power supply
  • Product Dimensions: 347×329×524mm
